Delphi FG0122 Fuel Pump Module Assembly (Genuine)

Description

Delphi FG0122 Fuel Pump Module Assembly (Genuine)

Cross Reference #:

• DELFG0122
• General Motors 19121635
• General Motors 19153719
• General Motors 25319806
• General Motors 25344808
• 25344810
• General Motors 25384291
• 9535070
• Bosch 67305
• ACDelco MU1059
• ACDelco MU1060
• ACDelco MU1515
• ACDelco MU1621
• ACDelco MU197
• Carter P74932M
• Airtex E3500M
• Airtex E3522M
• Spectra Premium SP6612M
• Master Parts Division E3599M
• Bosch 67429
• DENSO Auto Parts 953-5070
• Spectra Premium SP6690M
• AutoZone EFG0122
• General Motors 19332083
• Precision Fuel A30255

Applications:

• GMC Sierra 3500 (2001-2003)
• Chevrolet Silverado 3500 (2001-2003)

Specifications:

• Fuel Level Sender Assembly Included Yes
• Package Contents Fuel Pump Module Assembly w/Float Arm, Seal, Splices, Wire Harness, Instruction Sheet
• System Pressure 62 psi
• Item Grade Standard Replacement
• Vapor Pressure Sensor Yes
• Outlet Outside Diameter 0.375 IN
• Voltage 12.0 2H
• Fuel Type Gas
• Regulator Included No
• Maximum Pressure 109.0 PS
• Terminal Type Blade
• Gasket Or Seal Included Yes
• Terminal Quantity 4
• Lock Ring Included No
• Terminal Gender Male
• Strainer Included Yes
• Inlet Type Strainer
• Outlet Type Quick Connect
• Outlet Quantity 3
• In Tank or External In Tank
• Resistance Ohms Empty 40.0 82
• Resistance Ohms Full 250.0 82
• Internal Or External Strainer Internal
• Pump Type Electric
• Average Current Draw 10.0 68
• Average Flow Rating 24.0 GPH
