Maxon 225216 Mud Guard Assembly, Mud Flap Installation Kit

Description

Maxon 225216 Mud Guard Assembly, Mud Flap Installation Kit

Kit Includes:

• (1) P/N 210496-01 – 96” MUD GUARD SUPPORT
• (1) P/N 225212 – 96” MUD GUARD CLAMP
• (1) P/N 228795 – MUD FLAP 24” X 96”
• (2) P/N 289886-01 – MUD FLAP ANGLE SUPPORT
• (2) P/N 289887-01  – FLAT 2” X 9-3/4” X 3/16”
• (13) P/N 900009-6 – CAP SCREW 5/16”-18 X 1-1/2” LG
• (26) P/N 902000-7 – FLAT WASHER, 5/16”
• (13) P/N 901001 – LOCK NUT, 5/16”-18
• (5) P/N 901624-05 – HEX FRAME BOLT 3/8”-16 X 1-1/4” LG
• (5) P/N 901023-03 – FLANGE LOCK NUT 3/8”-16

Cross Reference #:

• MX-225216
• MAX225216
• MAX-225216
• MX225216

Installation Manual
